We are instrumental in offering a wide range of Stainless Steel 309 Sheet, 309 Stainless Steel Sheets,ASME SA240 304, 304L, 304H, 309,309S,ASTM A240 Stainless Steel 309 Sheets to the customers at highly competitive prices. These products are manufactured using high-grade stainless steel, at our vendors' end. Besides, we aim at delivering the ordered products at the clients' end within the stipulated time frame. Following are the specifications of these products.
Jainex Steel and Metal exports 309 Stainless Steel Sheets,ASME SA240 304, 304L, 304H, 309,309S,ASTM A240 Stainless Steel 309 Sheets to countries like Saudi, Arabia, Bangladesh,
United Arab Emirates, Brazil, Russia, Indonesia, Egypt, Iran, Kuwait, Taiwan, Oman, Qatar,
South Africa, Australia, Pakistan, Malaysia.

Stainless Steel 309 sheet Specification| Item | Stainless Steel 309 sheet(Hot rolled, cold rolled) |
| Thickness | 0.3mm~200mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc |
| Surface | the surface and finish of stainless steel 309 sheet: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Brand: | Indian Origin, European Origin, Japanese Origin, US Origin, Korea Origin, Thailand Origin, Taiwan Origin |
| Manufacturer: | POSCO, Aperam, Jindal Stainless, DKC Korea, Thyssenkrup, Baosteel, TISCO, Arcelor Mittal, VDM, Nippon Metal, Outokumpu |
| Package | Shrink-wrapped ,Carton boxes,Wooden pallets,Wooden boxes ,Wooden crates Etc. required. |
| Export to | India,
Indonesia,
Malaysia,
Singapore,
Saudi Arabia,
Qatar,
UAE,
Iran,
Iraq,
Oman,
South Africa, Nigeria, Kenya, Italy, UK, Brazil, Russia , Egypt , Kuwait , Taiwan, Australia . |
Stainless Steel 309 sheet Equivalent Grades| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN |
| SS 309 | 1.4828 | S30900 | SUS 309 | - | - | - | - |

Chemical Properties Of 309 Stainless Steel sheet:Grade |
Fe |
Cr |
Ni |
Mn |
Si |
C |
P |
S |
|
309 |
60% |
23% |
14% |
2% |
1% |
0.20% |
0.045% |
0.030% |

Mechanical Properties Of 309 Stainless Steel sheet:The mechanical properties of grade 309 Stainless Steel sheet are displayed in the following table.
| Grade | Yield Strength 0.2% Offset0 |
Ultimate Tensile Strength |
Elongation in 2 in. |
Hardness | ||
| - | psi (min.) | (MPa) | psi (min.) | (MPa) | % (min.) | (max.) |
| 309 | 45,000 | 310 | 85,000 | 586 | 50 | 202 (HBN) |
Stainless Steel 309 sheet Physical Properties| Grade | Density (lb / cu. in.) | Specific Gravity | Specific Heat (Btu/lb/Deg F – [32-212 Deg F]) | Electrical Resistivity (microhm-cm (at 68 Deg F)) | Melting Point (Deg F) | Modulus of Elasticity Tension |
| 309 | 0.287 | 7.9 | 0.12 | 468 | 2650 | 29 |

309 Stainless Steel sheet Application

309 Stainless Steel sheet ProcessingThe majority of normal processing can be performed on 309 Stainless Steel sheet Jainex Steel & Metal Offers Following Processing for 309 Stainless Steel sheet:

309 Stainless Steel sheet Stock Available
Tisco Stainless Steel 309 sheet
SS 309 Perforated sheet
Stainless Steel 309 UNS S31635 sheet
A 240 Chequered 309 sheet
Aperam Stainless Steel 309 sheet
Stainless Steel 309 sheet
A 240 309 sheet
SS 309 Embossed sheet
Outokumpu SS 309 sheet
SA 240 309 Stainless Steel sheet
Bright Hammered Pattern Decorative SS 309 sheet
Jindal Stainless Steel 309 sheet
SS DIN 1.4571 sheet
ThyssenKrupp Stainless Steel 309 sheet
ASTM A240 Stainless Steel 309 sheet
Surface Polishing SS 309 sheet
309 Stainless Steel HR sheet
309 Stainless Steel Chequered sheet
309 Stainless Steel Golden Laser Pattern sheet
Super thin-Mirror surface BA ss 309 sheet
Super Austenitic SS 309 sheet
ASTM A240 309 sheet
JMSS cold rolled ss 309 sheet
Cold Rolled No.1 Finish SS 309 sheet
SEW 400 Stainless Steel 309 sheet
Hot Rolled Stainless Steel 309 sheet
Sales Promotion SS 309 sheet
Cr Stainless Steel 309 sheet
SS 309 Mill Test Certificate sheet
ASTM A240 309 sheet
Cold rolled, bright annealed 309 sheet
Ground Stainless Steel 309 sheet
Hot Selling AISI SS 309 sheet
SS 309 Rose Golden sheet
Surface coated Stainless Steel 309 sheet
Satin finish Stainless Steel 309 sheet
AISI stainless steel 309 armor sheet
Satin finish Stainless Steel 309 sheet
Mirror Finish SS 309 sheet
SS 309 sheet Gold Brush Finish
309 Stainless Steel CR sheet
309 Stainless Steel 2B sheet
309 Stainless Steel B. Q. Profile sheet
Best selling 4'x8' mirror finished ss 309 sheet
Decorative hairline inox cold rolled ss 309 sheet
Hair Line Finish SS 309 sheet
Laser cutting ss 309 sheet
Tisco Supplier 3mm Thickness Stainless Steel 309 sheet
Decorative Stainless Steel 309 sheet
Scotch Brite SS 309 sheet
Baosteel Stainless Steel 309 sheet
Stainless Steel Cladding 309 sheet
Black SS 309 sheet 4mm Thick
Bright-pickled Stainless Steel 309 sheet
Cold rolled, heat treated 309 sheet
3mm Cold Rolled AISI SS 309 sheet
Mill Supply SS 309 sheet
Grade Prime SS 309 sheet
Carpenter Custom 450 Stainless Steel 309 sheet
Cut to Size Stainless Steel 309 sheet
Non Magnetic Polishing Stainless Steel 309 sheet
ASME SA240 309 sheet
309 Stainless Steel Blank sheet
309 Stainless Steel Perforated sheet
Embossed ss 309 sheet
Cheap cold rolled ss 309 sheet with best price
Brush finish ss 309 sheet price list
SS URANUS B6 309 sheet
2B SUS SS 309 sheet
Food Grade Stainless Steel 309 sheet
No. 4 PVC Coated SS 309 sheet
SS 309 sheet Blasted Tin-Gold Rose
2mm ASTM SS 309 sheet
Stainless Steel Corrugated 309 sheet
ASTM B625 309 sheet
Brushed or dull polished Stainless Steel 309 sheet
Cold rolled, heat treated, pickled 309 sheet
10K Mirror Finish Surface SS 309 sheet
Gold Etched SS 309 sheet
18 Gauge SS 309 sheet
Patterned Stainless Steel 309 sheet
#4 Finish Stainless Steel 309 sheet
Patterned Stainless Steel 309 sheet
Passenger Elevator Cabin SS 309 sheet

Packaging:We Jainex steel & Metal Ensure the best quality of Packing , because its play important role especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put extraordinary concern regarding packaging.
We pack our goods in numerous ways based on the products. We pack our products in multiple ways, such as:--




Testings (Destructive, Non Destructive):
