Hastelloy C276 Alloy
HASTELLOY® C-276 alloy (UNS N10276) was the first wrought, nickel-chromium-molybdenum material to alleviate concerns over welding (by virtue of extremely low carbon and silicon contents). As such, it was widely accepted in the chemical process and associated industries, and now has a 50-year-old track record of proven performance in a vast number of corrosive chemicals.
Like other nickel alloys, it is ductile, easy to form and weld, and possesses exceptional resistance to stress corrosion cracking in chloride-bearing solutions (a form of degradation to which the austenitic stainless steels are prone). With its high chromium and molybdenum contents,it is able to
withstand both oxidizing and non-oxidizing acids, and exhibits outstanding resistance to pitting and crevice attack in the presence of chlorides and other halides. Furthermore, it is very resistant to sulfide stress cracking and stress corrosion cracking in sour, oilfield environments.
HASTELLOY® C-276 alloy is available in the form of plates, sheets, strips, billets, bars, wires, pipes, tubes, and covered electrodes. Typical chemical process industry (CPI) applications include reactors, heat exchangers, and columns.
What are the characteristics of Hastelloy C276 Alloy?
- Excellent corrosion resistance in reducing environments.
- Exceptional resistance to strong solutions of oxidizing salts, such as ferric and cupric chlorides.
- High nickel and molybdenum contents providing good corrosion resistance in reducing environments.
- Low carbon content which minimizes grain-boundary carbide precipitation during welding to maintain resistance to corrosion in heat-affected zones of welded joints.
- Resistance to localized corrosion such as pitting and stress-corrosion cracking.
- One of few materials to withstand the corrosive effects of wet chlorine gas, hypochlorite and chlorine dioxide.
Hastelloy C-276 alloy can be forged, hot-upset and impact extruded. Although the alloy tends to work-harden, you can have it successfully spun, deep-drawn, press formed or punched. All of the common methods of welding can be used, although the oxyacetylene and submerged arc processes are not recommended when the fabricated item is for use in corrosion service.
Hastelloy C276 Alloy Specification
| Specifications | ASTM B575, ASME SB575 |
| Thickness | 0.03 mm to 3 mm |
| Coil Width | 3 mm and above |
| Finish | Hot rolled (HR), Cold rolled (CR), SATIN (Met with Plastic Coated), Galvanized etc. |
| Brand: | Indian Origin, European Origin, Japanese Origin, US Origin, Korea Origin, Thailand Origin, Taiwan Origin |
| Manufacturer: | POSCO, Aperam, Jindal Stainless, DKC Korea, Thyssenkrup, Baosteel, TISCO, Arcelor Mittal, VDM, Nippon Metal, Outokumpu |
| Package | Shrink-wrapped ,Carton boxes,Wooden pallets,Wooden boxes ,Wooden crates Etc. required. |
| Export to | India,
Indonesia,
Malaysia,
Singapore,
Saudi Arabia,
Qatar,
UAE,
Iran,
Iraq,
Oman,
South Africa, Nigeria, Kenya, Italy, UK, Brazil, Russia , Egypt , Kuwait , Taiwan, Australia . |
Hastelloy C276 Alloy Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN | OR |
| Hastelloy C276 | 2.4819 | N10276 | NW 0276 | ХН65МВУ | NiMo16Cr15W | ЭП760 |
Chemical Properties Of Hastelloy C276 Alloy:
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
Mechanical Properties Of Hastelloy C276 Alloy:
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
Hastelloy C276 Alloy Application
- Hastelloy C276 Alloy Used in Tractor
- Hastelloy C276 Alloy Used in Automotive Trim
- Hastelloy C276 Alloy Used in Stamped Machined Products
- Hastelloy C276 Alloy Used in Cookware
- Hastelloy C276 Alloy Used in Appliances
- Hastelloy C276 Alloy Used in Kitchen
- Hastelloy C276 Alloy Used in Foodservice Equipment
- Hastelloy C276 Alloy Used in Sinks
- Hastelloy C276 Alloy Used in Railway Cars
- Hastelloy C276 Alloy Used in Trailers
Hastelloy C276 Alloy Processing
The majority of normal processing can be performed on Hastelloy C276 Alloy Jainex Steel & Metal Offers Following Processing for Hastelloy C276 Alloy:
- Hastelloy C276 Alloy Testing
- Hastelloy C276 Alloy Cutting
- Hastelloy C276 Alloy Grinding
- Hastelloy C276 Alloy Forming Drilling/ Machining
Hastelloy C276 Alloy Stock Available
ASME SB575 Hastelloy Foils
Hastelloy GOST ХН65МВУ Strip
Hastelloy DIN 2.4819 Coils
Alloy UNS N10276 Shim Foil Dealer
Hastelloy UNS N10276 Shim Foil Manufacturer
Hastelloy C276 Coils
C276 Hastelloy Strip
ASTM B575 Hastelloy Strips
Hastelloy UNS N10276 Strip Coils
ASTM SB575 Hastelloy Coils Suppliers
Hastelloy Coils Strips Foils
Hastelloy UNS N10276 Coils Strips Foils
Hastelloy Coils Strips Foils Stockist in India
Top Quality Hastelloy C276 Coils
Hastelloy Foil Distributors
Hastelloy C276 Strip Supplier
Packaging:
We Jainex steel & Metal Ensure the best quality of Packing , because its play important role especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put extraordinary concern regarding packaging.
We pack our goods in numerous ways based on the products. We pack our products in multiple ways, such as:--
- Boxes and Crates
- Shrink-wrapped
- Carton boxes
- Wooden pallets
- Wooden boxes
- Wooden crates
Testings (Destructive, Non Destructive):
- Positive Material Identification - PMI Testing
- Chemical Analysis - Spectro Analysis
- Mechanical Testing Such as Tensile, Elongation, Reduction of Area
- Micro Test
- Macro Test
- Hardness Test
- Pitting Resistance Test
- Intergranular Corrosion (IGC) Test
- Flaring Test
- Flattening Test
- Hydrostatic Test
- Hydrogen-Induced Cracking (HIC) Test, NACE TM0284
- Sulfide Stress Corrosion Cracking (SSC), NACE TM 0177
- Radiography Test
- Dye Penetrant Test (DP Test)
- Ultra Sonic Test (UT)
- Eddy Current Testing
- Impact Test
- Bend Test
